Voith IPV5 - 40 1011
Displacement per Revolution: 41.0
cm
3
Speed Range:
Minimum Speed: 400
min
−1
Maximum Speed: 2,800
min
−1
Delivery at 1,500 rpm: 61.5 l/min
Pressure:
Continuous Pressure: 315 bar
Peak Pressure at 1,500 rpm: 345 bar
Peak Pressure at nmax: 315 bar
Voith IPV 3 - 81
Displacement per Revolution: 8.2
cm
3
Speed Range:
Minimum Speed: 400
min
−1
Maximum Speed: 3,600
min
−1
Delivery at 1,500 rpm: 12.3 l/min
Pressure:
Continuous Pressure: 330 bar
Peak Pressure at 1,500 rpm: 345 bar
Peak Pressure at nmax: 345 bar
Voith IPVP 6 - 100 1011
Displacement per Revolution: 101.3
cm
3
Speed Range:
Minimum Speed: 400
min
−1
Maximum Speed: 2,100
min
−1
Delivery at 1,500 rpm: 151.9 l/min
Pressure:
Continuous Pressure: 250 bar
Peak Pressure at 1,500 rpm: 300 bar
Peak Pressure at nmax: 270 bar
